18 AWG 2-Conductor LED Strip Wire, Red/Black, White Jacket, 164ft (50m)

Designed for single-color LED lighting, this 18 AWG stranded wire uses two red and black conductors with a white outer coating. The lighter exterior is useful when the wire remains visible in light-colored installation areas.

The 164 ft (50 m) roll is intended for larger installations, repeated custom sections, or several installation areas using the same wire specification. A larger continuous supply reduces the need to combine several smaller rolls when the same wire is used repeatedly.

• For single-color LED lighting
• 2 conductors: red and black
• White outer coating
• Wire gauge: 18 AWG
• Current: 1.63 A
• Overall size: 2.0 × 4.0 mm
• PVC insulation
• Maximum temperature: 176°F (80°C)
• Length: 164 ft (50 m)

Technical Specifications
